0603 SMD LED (results: 301)
| Product | Cart |
Manufacturer
|
Diode type
|
Mounting
|
Case
|
LED colours
|
Brightness
|
Viewing angle
|
LED diode current
|
Wavelength (nm)
|
Diode lens
|
Power
|
Front
|
Nominal voltage
|
Wavelength range
|
Forvard volatge [UF]
|
Colour temperature
|
Colour temperature (range)
|
Operating temperature (range)
|
Chromatic coordinates
|
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LS L296-P2Q2-1 OSRAM
LED SMD 0603; red; luminosity: 56-71mcd; viewing angle: 160°; diode current: 60mA Wavelength: 627-633nm; working voltage: 1,8-2,3V
|
|||||||||||||||||||||
Rys.LS L296-P2Q2-1
|
OSRAM | LED | SMD | 0603 | Red | 56mcd ~ 71mcd | 160° | 60mA | Flat | 1,8V ~ 2,3V | 627nm ~ 633nm | -40°C ~ 100°C | |||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
LY-L296-Q2R2-26 OSRAM
LED SMD 0603; yellow; luminosity: 90-180mcd; viewing angle: 160°; diode current: 30mA; Wavelength: 570nm; diffused; working voltage: 1,9-2,4V
|
|||||||||||||||||||||
|
Rys.0603
|
OSRAM | LED | SMD | 0603 | Yellow | 90mcd ~ 180mcd | 160° | 30mA | Diffusive | Flat | 1,9V ~ 2,4V | 580nm ~ 595nm | -40°C ~ 100°C | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
S192BC-B4-1AG
LED SMD 0603 (1608); blue (470nm); luminosity 130 - 200 mcd; waterclear; viewing angle 130°; IF=20mA; VF=3.2V; dimensions:1.6 x 0.8 x 0.6mm
|
|||||||||||||||||||||
Rys.OLS.03w0.6
|
LED | SMD | 0603 | Blue | 150mcd | 130° | 20mA | 470nm | 3,2V | ||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
OSB50603C1D
LED SMD 0603 (1608); blue (470nm); luminosity 14 - 40 mcd; clear; viewing angle 120°; IF=20mA; VF=3.4V; dimensions:1.6 x 0.8 x 0.6mm
|
|||||||||||||||||||||
|
Rys.OLS.03w
|
LED | SMD | 0603 | Blue | 20mcd | 120° | 20mA | 470nm | 3,4V | ||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
OLCS.03w0020
LED SMD 0603 (1608); red (625nm); luminosity 15 - 50 mcd; waterclear; viewing angle 120°; IF=5mA; VF=1.8V;
|
|||||||||||||||||||||
Rys.OLCS.03w0020
|
LED | SMD | 0603 | Red | 15mcd | 140° | 20mA | 660nm | 1,8V | ||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
LG L29K-G2J1-24 OSRAM
LED SMD 0603 green; luminosity: 2,24-5,6mcd viewing angle 160°; IF= 20mA; VF=1.7-2V
|
|||||||||||||||||||||
|
Rys.OLS.03w
|
OSRAM | LED | SMD | 0603 | Green | 3mcd | 160° | 20mA | 570nm | 1,8V | |||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
OLNS.03w0700
LED SMD 0603 green luminosity: 600-700mcd; convex
|
|||||||||||||||||||||
Rys.OLNS.03w0700
|
LED | SMD | 0603 | ||||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
OLZ.03c0012
LED SMD 0603 green; 12mcd; 568nm Viewing angle 120°; IF=20mA; VF= 2.2V
|
|||||||||||||||||||||
|
Rys.OLZ.03C0012
|
KingBright | LED | SMD | Green | 12mcd | 120° | 20mA | 568nm | 2,2V | ||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
KP-1608YC Kingbright
LED SMD 0603; yellow; luminosity: 3-8mcd; viewing angle: 150°; diode current: 20mA Wavelength: 588nm; transparent; power: 75mW; working voltage: 2,1-2,5V
|
|||||||||||||||||||||
|
Rys.OLY.KP-1608YC
|
KingBright | LED | SMD | 0603 | Yellow | 3mcd ~ 8mcd | 150° | 20mA | 588nm | Transparent | 75mW | Flat | 2,1V ~ 2,5V | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
KP-1608LSGD Kingbright
LED SMD 0603; green; luminosity: 0,1-0,35mcd; viewing angle: 160°; diode current: 20mA Wavelength: 568nm; transparent; power: 62,5mW; working voltage: 1,9-2,25V
|
|||||||||||||||||||||
|
Rys.OLZ.KP-1608LSGD
|
KingBright | LED | SMD | 0603 | Green | 0,1mcd ~ 0,35mcd | 160° | 20mA | 568nm | Transparent | 62,5mW | Flat | 1,9V ~ 2,25V | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
KPT-1608SGD Kingbright
LED SMD 0603; green; luminosity: 3-8mcd; viewing angle: 160°; diode current: 20mA Wavelength: 568nm; transparent; power: 62,5mW; working voltage: 2,2-2,5V
|
|||||||||||||||||||||
|
Rys.OLZ.KPT-1608SGD
|
KingBright | LED | SMD | 0603 | Green | 3mcd ~ 8mcd | 160° | 20mA | 568nm | Diffusive | 62,5mW | Flat | 2,2V ~ 2,5V | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
KPT-1608MGC Kingbright
LED SMD 0603; green; luminosity: 20-60mcd; viewing angle: 120°; diode current: 20mA Wavelength: 570nm; transparent; power: 75mW; working voltage: 2,1-2,5V
|
|||||||||||||||||||||
|
Rys.OLZ.KPT-1608MGC
|
KingBright | LED | SMD | 0603 | Green | 20mcd ~ 60mcd | 120° | 30mA | 570nm | Transparent | 75mW | Flat | 2,1V ~ 2,5V | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
KPH-1608YD Kingbright
LED SMD 0603; yellow; luminosity: 3-8mcd; viewing angle: 120°; diode current: 20mA Wavelength: 588nm; transparent; power: 105mW; working voltage: 2,1-2,5V
|
|||||||||||||||||||||
|
Rys.OLY.KPH-1608YD
|
KingBright | LED | SMD | 0603 | Yellow | 3mcd ~ 8mcd | 120° | 20mA | 588nm | Diffusive | 105mW | Flat | 2,1V ~ 2,5V | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLA.ASMT-CA00
|
Broadcom | LED | SMD | 0603 | Amber | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLN.ASMT-CB00
|
Broadcom | LED | SMD | 0603 | Blue | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLC.ASMT-CR00
|
Broadcom | LED | SMD | 0603 | Red | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
ASMT-RA45-AP932 Broadcom
LED SMD 0603; amber; luminosity: 57-90mcd; viewing angle: 145°; diode current: 20mA Transparent; working voltage: 1,6-2,4V; power: 68mW
|
|||||||||||||||||||||
|
Rys.OLA.ASMT-RA45-AP932
|
Broadcom | LED | SMD | 0603 | Amber | 57mcd ~ 90mcd | 145° | 20mA | Diffusive | 48mW | 1,6V ~ 2,4V | 591nm ~ 593nm | -40°C ~ 100°C | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
HSMC-C130 Broadcom
LED SMD 0603; red; luminosity: 28,5-87mcd; viewing angle: 110°; diode current: 20mA Wavelength: 626-635nm; diffused; working voltage: 2,05-2,4V; power: 48mW
|
|||||||||||||||||||||
|
Rys.OLC.HSMC-C130
|
Broadcom | LED | SMD | 0603 | Red | 28,5mcd ~ 87mcd | 110° | 20mA | Diffusive | 48mW | 2,05V ~ 2,4V | 626nm ~ 635nm | -40°C ~ 85°C | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
HSMC-C191-T0000 Broadcom
LED SMD 0603; red; luminosity: 285-1125mcd; viewing angle: 125°; diode current: 20mA Wavelength: 626-637nm; diffused; working voltage: 1,6-2,4V; power: 60mW
|
|||||||||||||||||||||
|
Rys.OLC.HSMC-C191-T0000
|
Broadcom | LED | SMD | 0603 | Red | 285mcd ~ 1125mcd | 125° | 25mA | Diffusive | 60mW | 1,6V ~ 2,4V | 626nm ~ 637nm | -40°C ~ 85°C | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
HSMC-C197 Broadcom
LED SMD 0603; red; luminosity: 28,5-90mcd; viewing angle: 130°; diode current: 25mA Wavelength: 626-637nm; diffused; working voltage: 1,9-2,4V; power: 60mW
|
|||||||||||||||||||||
|
Rys.OLC.HSMC-C197
|
Broadcom | LED | SMD | 0603 | Red | 28,5mcd ~ 90mcd | 130° | 25mA | Diffusive | 60mW | 1,9V ~ 2,4V | 626nm ~ 637nm | -40°C ~ 85°C | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLP.HSMD-C191
|
Broadcom | LED | SMD | 0603 | Orange | 2.6 - 8 mcd | 170° | 20mA | 604nm | Diffusive | 52mW | 2,2V ~ 2,6V | -40°C ~ 85°C | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLZ.HSME-C190
|
Broadcom | LED | SMD | 0603 | Green | 18mcd ~ 50mcd | 170° | 20mA | 572nm | Diffusive | 52mW | Flat | 2,1V ~ 2,6V | -40°C ~ 85°C | |||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLYZ.HSMF-C166
|
Broadcom | LED | SMD | 0603 | Yellow-Green | 15mcd | 120° | 20mA | 589nm | Diffusive | 52mW | -40°C ~ 85°C | |||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLNA.HSMF-C169
|
Broadcom | LED | SMD | 0603 | Blue-Amber | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLZ.HSMG-C197
|
Broadcom | LED | SMD | 0603 | Green | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLP.HSML-C120
|
Broadcom | LED | SMD | 0603 | Orange | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLP.HSML-C190
|
Broadcom | LED | SMD | 0603 | Orange | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLP.HSML-C191
|
Broadcom | LED | SMD | 0603 | Orange | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
HSMM-C190 Broadcom
LED SMD 0603; green; luminosity: 45-120mcd; viewing angle: 130°; diode current: 20mA Wavelength: 523-525nm; diffused; working voltage: 3,3-3,9V; power: 78mW
|
|||||||||||||||||||||
|
Rys.OLZ.HSMM-C190
|
Broadcom | LED | SMD | 0603 | Green | 45mcd ~ 120mcd | 130° | 20mA | 78mW | Flat | 3,3V ~ 3,9V | 523nm ~ 525nm | -40°C ~ 85°C | ||||||||
|
|
Item available on a request
|
||||||||||||||||||||
|
Rys.OLZ.HSMQ-C190
|
Broadcom | LED | SMD | 0603 | Green | -40°C ~ 85°C | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||
