Potentiometers (results: 1063)
| Product | Cart |
Dimensions
|
Resistance
|
Power
|
Operating temperature (range)
|
Rotation angle
|
Terminal pitch
|
Manufacturer
|
Caseback color
|
Indicator colour
|
Number of rotations
|
Temperature coefficient
|
Tolerance
|
Colour
|
Mounting
|
Material
|
Shaft diameter
|
Tolerance
|
Characteristic
|
Kind of potentiometer
|
Knob type
|
Type of potentiometer
|
Accessories type
|
IP rating
|
Shape
|
Terminal pitch
|
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Single turn cermet trimmer; 3362M; 500R
Effective electrical travel: 210° ± 10°; THT; 3362M=T73XW=25V; 6,90x7,10x4,8mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3362M
|
6,9x7,1x4,8mm | 500 Ohm | 0,5W | -55°C ~ 125°C | 210° | N/A | 100ppm/°C | 10% | THT | Linear | Single-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmer; 3329S; 20kR
effective electrical travel: 210° ± 10°; 8,38x6,6mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3329S
|
8,38x6,6mm | 20 kOhm | 0,5W | -55°C ~ 125°C | 210° | 100ppm/°C | 10% | THT | Single-turn | Mounting | |||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
P16NP222MAB15 Vishay Potentiometer
Single turn shaft potentiometer; 2,2kR; soldered; linear characteristics; 16x8mm; shaft diameter: 10mm; power: 1W; tolerance: 20%; 150 ppm/°C; 10V; operating temperature: -40°C÷85°C
|
|||||||||||||||||||||||||||
Rys.P16NP
|
16x8mm | 2,2 kOhm | 1W | -40°C ~ 85°C | VISHAY | 150ppm/°C | 20% | For soldering | Linear | Single-turn | Shaft | ||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmer; 3386P; 50kR
Rotation angle 260°; THT; 3386P(Bourns) = 72P(Spectrol/Vishay) = 63P(BI-Techn) 9,5x6x9,5mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3386P
|
9,5x6x9,5mm | 50 kOhm | 0,5W | -55°C ~ 125°C | 260° | N/A | 100ppm/°C | 10% | THT | Linear | Single-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn trimmer potentiomter; RM-065; metal case; 200kR
horizontal; rotation angle: 210° ± 10°; THT; Vmax: 50V; 6,4x4,2mm; power: 0,1W (at 50°C); r= 5x5mm; operating temperature: -25÷60°C
|
|||||||||||||||||||||||||||
Rys.RM-065m
|
6,4x4,2mm | 200 kOhm | 0,1W | -25°C ~ 60°C | 210° | 5x5mm | THT | Single-turn | Mounting | ||||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
T73YP501KT20 Vishay Trimmer
Single turn cermet trimmer; 500R; turn: 240°; horizontal; THT; IP67; 7x6,6x4,7mm; power: 500mW; tolerance: 10%; 100ppm/°C; r=2,54x2,54mm; operating temperature: -25÷125°C
|
|||||||||||||||||||||||||||
Rys.T73YP
|
7x6,6x4,7mm | 500 Ohm | 0,5W | -25°C ~ 125°C | 240° | 2,54x2,54mm | VISHAY | 100ppm/°C | 10% | THT | Linear | Single-turn | Mounting | IP67 | |||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Multiturn cermet trimmer; 3269W; 10R
12 turns; SMD; 3269W=TS63Y,84W; 6,75x6,75x4,6mm; power: 0.25W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3269W
|
6,75x6,75x4,6mm | 10 Ohm | 0,25W | -55°C ~ 125°C | N/A | 12 | 100ppm/°C | 10% | SMD | Linear | Multi-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmeR 3323W; 20kR
Effective electrical travel: 210° ± 10°; 6,8x6,8x6,2mm; power: 0.50W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3323W
|
6,8x6,8x6,2mm | 20 kOhm | 0,5W | -55°C ~ 125°C | 210° | 100ppm/°C | 10% | THT | Mounting | ||||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
PT10LH01-103A2020 Piher Trimmer
Single turn carbon trimmer potentiometer; 10kR; vertical; rotation angle 220°; THT; 10,3x4,8mm; power: 0.15W; tolerance: ±20%; 300ppm/°C; r= 5x2,5mm; operating temperature: -25÷70°C
|
|||||||||||||||||||||||||||
Rys.PT10H
|
10,3x4,8mm | 10 kOhm | 150mW | -25°C ~ 70°C | 220° | r= 5x2,5mm | Piher | 300ppm/°C | THT | 20% | Linear | Single-turn | Mounting | ||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
P16NP472MAB15 Vishay Potentiometer
Single turn shaft potentiometer; 4,7kR; soldered; linear characteristics; 16x8mm; shaft diameter: 10mm; power: 1W; tolerance: 20%; 150 ppm/°C; 10V; operating temperature: -40°C÷85°C
|
|||||||||||||||||||||||||||
|
Rys.P16NP
|
16x8mm | 4,7 kOhm | 1W | -40°C ~ 85°C | VISHAY | 150ppm/°C | 20% | For soldering | Linear | Single-turn | Shaft | ||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
T93YA201KT20 Vishay Trimmer
Multiturn cermet trimmer; 200R; 22 turns; THT; 9.8x9.7x5mm; power: 0,5W; tolerance: 10%; 100ppm/°C; r=2.5mm; operating temperature: -55÷155°C; IP67
|
|||||||||||||||||||||||||||
Rys.T93YA
|
9.8x9.7x5mm | 200 Ohm | 0,5W | -55°C ~ 155°C | 2,5mm | VISHAY | 22 | 100ppm/°C | 10% | THT | Linear | Multi-turn | Mounting | IP67 | |||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmer; 3362M; 1kR
Effective electrical travel: 210° ± 10°; THT; 3362M=T73XW=25V; 6,90x7,10x4,8mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
|
Rys.3362M
|
6,9x7,1x4,8mm | 1,0 kOhm | 0,5W | -55°C ~ 125°C | 210° | N/A | 100ppm/°C | 10% | THT | Linear | Single-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmer; 3329S; 50kR
effective electrical travel: 210° ± 10°; 8,38x6,6mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
|
Rys.3329S
|
8,38x6,6mm | 50 kOhm | 0,5W | -55°C ~ 125°C | 210° | 100ppm/°C | 10% | THT | Single-turn | Mounting | |||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
T73YP102KT20 Vishay Trimmer
Single turn cermet trimmer; 1kR; turn: 240°; horizontal; THT; IP67; 7x6,6x4,7mm; power: 500mW; tolerance: 10%; 100ppm/°C; r=2,54x2,54mm; operating temperature: -25÷125°C
|
|||||||||||||||||||||||||||
|
Rys.T73YP
|
7x6,6x4,7mm | 1,0 kOhm | 0,5W | -25°C ~ 125°C | 240° | 2,54x2,54mm | VISHAY | 100ppm/°C | 10% | THT | Linear | Single-turn | Mounting | IP67 | |||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Multiturn cermet trimmer; 3269W; 20R
12 turns; SMD; 3269W=TS63Y,84W; 6,75x6,75x4,6mm; power: 0.25W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3269W
|
6,75x6,75x4,6mm | 20 Ohm | 0,25W | -55°C ~ 125°C | N/A | 12 | 100ppm/°C | 10% | SMD | Linear | Multi-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmeR 3323W; 50kR
Effective electrical travel: 210° ± 10°; 6,8x6,8x6,2mm; power: 0.50W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
|
Rys.3323W
|
6,8x6,8x6,2mm | 50 kOhm | 0,5W | -55°C ~ 125°C | 210° | 100ppm/°C | 10% | THT | Mounting | ||||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
P16NP103MAB15 Vishay Potentiometer
Single turn shaft potentiometer; 10kR; soldered; linear characteristics; 16x8mm; shaft diameter: 10mm; power: 1W; tolerance: 20%; 150 ppm/°C; 10V; operating temperature: -40°C÷85°C
|
|||||||||||||||||||||||||||
|
Rys.P16NP
|
16x8mm | 10 kOhm | 1W | -40°C ~ 85°C | VISHAY | 150ppm/°C | 20% | For soldering | Linear | Single-turn | Shaft | ||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
CA9PH2,5-25KA2020 SNP ACP Potentiometer
Single turn carbon potentiometer; CA9PH; 25kR; vertical; 9.8x10x4.8mm; power: 100mW; tolerance: 20%; r=5x2,5mm; operating temperature: -25°C÷70°C
|
|||||||||||||||||||||||||||
Rys.CA9PH
|
9.8x10x4.8mm | 25 kOhm | 0,1W | -25°C ~ 70°C | 5x2,5mm | ACP | 0 | THT | Single-turn | Mounting | N/A | ||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
T63YB501KT20 Vishay Trimmer
Multiturn cermet trimmer; 500R; 15 turns; THT; 6.8x6.8x5mm; power: 250mW; tolerance: 10%; 100ppm/°C; r=2,5mm; operating temperature: -55÷155°C; IP67
|
|||||||||||||||||||||||||||
Rys.T63YB
|
6.8x6.8x5mm | 500 Ohm | 0,25W | -55°C ~ 155°C | 2,5mm | VISHAY | 15 | 100ppm/°C | 10% | THT | Linear | Multi-turn | Mounting | IP67 | |||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
M64W204KB40 Vishay Trimmer
Multiturn cermet trimmer; 200kR; 23 turns; THT; 3296W(Bourns) = 64W(Spectrol/Vishay) = 67W(BI-Tech); 9.8x9.7x5mm; power: 0.5W; tolerance: 10%; 100ppm/°C; operating temperature: -55÷155°C; IP67
|
|||||||||||||||||||||||||||
Rys.M64W
|
9.8x9.7x5mm | 200 kOhm | 0,5W | -55°C ~ 155°C | VISHAY | 23 | 100ppm/°C | 10% | Linear | Multi-turn | Mounting | IP67 | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmer; 3362M; 2kR
Effective electrical travel: 210° ± 10°; THT; 3362M=T73XW=25V; 6,90x7,10x4,8mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
|
Rys.3362M
|
6,9x7,1x4,8mm | 2,0 kOhm | 0,5W | -55°C ~ 125°C | 210° | N/A | 100ppm/°C | 10% | THT | Linear | Single-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmer; 3329S; 100kR
effective electrical travel: 210° ± 10°; 8,38x6,6mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
|
Rys.3329S
|
8,38x6,6mm | 100 kOhm | 0,5W | -55°C ~ 125°C | 210° | 100ppm/°C | 10% | THT | Single-turn | Mounting | |||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Multiturn cermet trimmer; 3269W; 50R
12 turns; SMD; 3269W=TS63Y,84W; 6,75x6,75x4,6mm; power: 0.25W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3269W
|
6,75x6,75x4,6mm | 50 Ohm | 0,25W | -55°C ~ 125°C | N/A | 12 | 100ppm/°C | 10% | SMD | Linear | Multi-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
T18503KT10 Vishay Trimmer
Multiturn cermet trimmer; 50kR; 15 turns; THT; T18=M43P=89P=3006P; 19x4.8x6.4mm; power: 0.75W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C; IP67
|
|||||||||||||||||||||||||||
Rys.T18
|
19x4.8x6.4mm | 50 kOhm | 0,75W | -55°C ~ 125°C | VISHAY | 15 | 100ppm/°C | 10% | THT | Linear | Multi-turn | Mounting | IP67 | ||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmer; 3362M; 5kR
Effective electrical travel: 210° ± 10°; THT; 3362M=T73XW=25V; 6,90x7,10x4,8mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
|
Rys.3362M
|
6,9x7,1x4,8mm | 5,0kOhm | 0,5W | -55°C ~ 125°C | 210° | N/A | 100ppm/°C | 10% | THT | Linear | Single-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmer; 3329S; 200kR
effective electrical travel: 210° ± 10°; 8,38x6,6mm; power: 0.5W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
|
Rys.3329S
|
8,38x6,6mm | 200 kOhm | 0,5W | -55°C ~ 125°C | 210° | 100ppm/°C | 10% | THT | Single-turn | Mounting | |||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Multiturn cermet trimming potentiometer 3266W; 200kR
3266W(Bourns) = 74W(Spectrol/Vishay) = 64W(BI-Techn); 6,8x7,2mm; power: 0.25W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3266W
|
6,8x7,2mm | 200 kOhm | 0,25W | -55°C ~ 125°C | 12 | 100ppm/°C | 10% | THT | Linear | Multi-turn | Mounting | ||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
T73YP502KT20 Vishay Trimmer
Single turn cermet trimmer; 5kR; turn: 240°; horizontal; THT; IP67; 7x6,6x4,7mm; power: 500mW; tolerance: 10%; 100ppm/°C; r=2,54x2,54mm; operating temperature: -25÷125°C
|
|||||||||||||||||||||||||||
|
Rys.T73YP
|
7x6,6x4,7mm | 5,0kOhm | 0,5W | -25°C ~ 125°C | 240° | 2,54x2,54mm | VISHAY | 100ppm/°C | 10% | THT | Linear | Single-turn | Mounting | IP67 | |||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Multiturn cermet trimmer; 3269W; 100R
12 turns; SMD; 3269W=TS63Y,84W; 6,75x6,75x4,6mm; power: 0.25W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
Rys.3269W
|
6,75x6,75x4,6mm | 100 Ohm | 0,25W | -55°C ~ 125°C | N/A | 12 | 100ppm/°C | 10% | SMD | Linear | Multi-turn | Mounting | |||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
|
Single turn cermet trimmeR 3323W; 200kR
Effective electrical travel: 210° ± 10°; 6,8x6,8x6,2mm; power: 0.50W; tolerance: ±10%; 100ppm/°C; operating temperature: -55÷125°C
|
|||||||||||||||||||||||||||
|
Rys.3323W
|
6,8x6,8x6,2mm | 200 kOhm | 0,5W | -55°C ~ 125°C | 210° | 100ppm/°C | 10% | THT | Mounting | ||||||||||||||||||
|
|
Item available on a request
|
||||||||||||||||||||||||||
