RBS100600

Symbol Micros: CZ RBS100600

83058

CZ RBS100600

Contractor Symbol:

Case : OQ-RBS10060x

Datasheet

Technical drawing Add to favourites

Tilt sensor, normally open switch, THT, tilt angle: 25°+20°/-22° contact: 10mA/5VDC/50Ω max, endurance: 100000 cycles, temperature: -25÷85°C

Parameters

Dimensions:	2.45x5x4.7mm
Tilt angle [°]:	25+20/-22
Sensor:	Tilt
Type of switch:	NO
Mounting:	THT
Manufacturer:	OncQue

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Dimensions:	2.45x5x4.7mm
Tilt angle [°]:	25+20/-22
Sensor:	Tilt
Type of switch:	NO
Mounting:	THT
Manufacturer:	OncQue
