B82725A2103N001 TDK Power inductor

Symbol Micros: D B82725a2103n1

308252

D B82725a2103n1

Contractor Symbol:

Case : Rys.B82725A

Datasheet

Technical drawing Add to favourites

Power inductor; THT; 1.8mH; 30%; 10A; 14mR; dimensions: 44x42.4x25mm; operating temperature: -40°C~125°C

Parameters

Current:	10A
Dimensions:	44x42.4x25mm
Inductance:	1,8mH
Inductor type:	Power
Manufacturer:	TDK
Mounting:	THT
Operating temperature (range):	-40°C ~ 125°C

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Current:	10A
Dimensions:	44x42.4x25mm
Inductance:	1,8mH
Inductor type:	Power
Manufacturer:	TDK
Mounting:	THT
Operating temperature (range):	-40°C ~ 125°C
Resistance:	14 mOhm
Tolerance:	30%
