SMD Power Inductor; 100uH

Symbol Micros: D DL4N-100

121714

D DL4N-100

Contractor Symbol:

Case : Rys.DL4N

Datasheet

Technical drawing Add to favourites

SMD power inductor; inductance: 100uH; 20%; current: 360mA; resistance: 2.21R; dimensions: 4.5x3.2x2.6mm

Parameters

Dimensions:	4.5x3.2x2.6mm
Inductance:	100uH
Inductor type:	Power
Manufacturer:	N/A
Mounting:	SMD
Current:	0,36A
Resistance:	2,21 Ohm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Dimensions:	4.5x3.2x2.6mm
Inductance:	100uH
Inductor type:	Power
Manufacturer:	N/A
Mounting:	SMD
Current:	0,36A
Resistance:	2,21 Ohm
Tolerance:	20%
