RN 114-2-02-4M2 Schaffner Inductor

Symbol Micros: D RN114-2-02-4M2

258267

D RN114-2-02-4M2

Contractor Symbol:

Case : Rys.RN114

Datasheet

Technical drawing Add to favourites

Inductor; THT; 4.2mH; -30%, +50%; 2A; 100mR; dimensions: 20.1x12.5mm; operating temperature: -40°C~100°C

Parameters

Manufacturer:	Schaffner
Mounting:	THT
Inductance:	4,2mH
Current:	2A
Resistance:	0,1 Ohm
Tolerance:	-30%,+50%
Operating temperature (range):	-40°C ~ 100°C

All parameters

Manufacturer:: SCHAFFNER Manufacturer part number: RN114-2-02-4M2 RoHS Case style: Rys.RN112 Datasheet

In stock:

50 pcs.

Quantity of pcs.	1+	5+	25+	50+	200+
Net price (EUR)	1,8151	1,3424	1,1533	1,1132	1,0683

Add to comparison tool Add inquiry (RFQ)

Packaging:
25/50 Quantity (multiple: 1)

- +

Manufacturer:: SCHAFFNER Manufacturer part number: RN114-2-02-4M2 Case style: Rys.RN114

External warehouse:

200 pcs.

Quantity of pcs.	5+ (Need a significantly larger quantity? Ask for price).
Net price (EUR)	1,2504

Add to comparison tool Add inquiry (RFQ)

Packaging:
5

Place an order

Delivery within 4-7 business days.
Minimum order amount
must exceed 20 Euro.

• Parameters

Manufacturer:	Schaffner
Mounting:	THT
Inductance:	4,2mH
Current:	2A
Resistance:	0,1 Ohm
Tolerance:	-30%,+50%
Operating temperature (range):	-40°C ~ 100°C
Dimensions:	20.1x12.5mm
