B82472G4473M000 TDK Power Inductor

Symbol Micros: D SP073/0047.0 TDK

501699

D SP073/0047.0 TDK

Contractor Symbol:

Case : Rys.B82472G4

Datasheet

Technical drawing Add to favourites

SMD power inductor; inductance: 47uH; 20%; current: 860mA; resistance; 300mR; dimensions; 7.3x7.3x3.4mm; operating temperature: -55°C ~ 125°C

Parameters

Dimensions:	7.3x7.3x3.5mm
Inductance:	47uH
Inductor type:	Power
Manufacturer:	TDK
Mounting:	SMD
Current:	0,86A
Resistance:	0,30 Ohm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Dimensions:	7.3x7.3x3.5mm
Inductance:	47uH
Inductor type:	Power
Manufacturer:	TDK
Mounting:	SMD
Current:	0,86A
Resistance:	0,30 Ohm
Operating temperature (range):	-55°C ~ 125°C
Tolerance:	20%
