B82422T1153J000 TDK Inductor

Symbol Micros: D1210S0015.00/0.130A/2.8Rj

125644

D1210S0015.00/0.130A/2.8Rj

Contractor Symbol:

Case : Rys.B82422T

Technical drawing Add to favourites

Inductor; SMD1210; 15uH; 5%; 0.130A; 2.8R; 2,52MHz; operating temperature: -55°C~125°C

Parameters

Manufacturer:	TDK
Mounting:	SMD
Case:	1210
Inductance:	15uH
Current:	0,13A
Resistance:	2,8 Ohm
Tolerance:	5%

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Manufacturer:	TDK
Mounting:	SMD
Case:	1210
Inductance:	15uH
Current:	0,13A
Resistance:	2,8 Ohm
Tolerance:	5%
Operating temperature (range):	-55°C ~ 125°C
