LH15-10B24ER2

Symbol Micros: DC LH15-10b24er2

85614

DC LH15-10b24er2

Contractor Symbol:

Case : MNd-62.0x45.0x30.0

Datasheet

Technical drawing Add to favourites

AC/DC Converter, 15W, Vout/Iout 24V/650mA, Viso 3000VAC, EFF 83% Special for Power Systems

Parameters

Output current 1:	650mA
Power:	15W
Input voltage range:	85~264 (120~370VDC)
Secondary voltage 1:	24V
Insulation breakdown voltage:	3000V

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Output current 1:	650mA
Power:	15W
Input voltage range:	85~264 (120~370VDC)
Secondary voltage 1:	24V
Insulation breakdown voltage:	3000V
