NN1-05S05ANT

Symbol Micros: DC NN1-05S05ANT

500315

DC NN1-05S05ANT

Contractor Symbol:

Case : MNs-13.2x8.5-8

Datasheet

Technical drawing Add to favourites

DC/DC converter; isolated; single output; 1W; Vin 4.5V~5.5V; Vout 5V; Iout 200mA; isolation 1500V; efficiency 85%; RoHS; Substitute: AM1L-0505S-NZ; B0505T-1WR3;

Parameters

Input voltage range:	4,5V~5,5V
Output current 1:	200mA
Power:	1W
Insulation breakdown voltage:	1500V
Secondary voltage 1:	5V

All parameters

Manufacturer:: AIPULNION Manufacturer part number: NN1-05S05ANT RoHS Case style: MNs-13.2x8.5-8 Datasheet

In stock:

50 pcs.

Quantity of pcs.	1+	4+	15+	50+	150+
Net price (EUR)	1,9102	1,4518	1,2526	1,1646	1,1230

Add to comparison tool Add inquiry (RFQ)

Packaging:
15/50 Quantity (multiple: 1)

- +

• Parameters

Input voltage range:	4,5V~5,5V
Output current 1:	200mA
Power:	1W
Insulation breakdown voltage:	1500V
Secondary voltage 1:	5V
