PFD6-18D05E2N3

Symbol Micros: DC PFD6-18D05E2N3

526296

DC PFD6-18D05E2N3

Contractor Symbol:

Case : Rys.AM5TxxxxZ(dz,sz)

Datasheet

Technical drawing Add to favourites

DC/DC converter; isolated; dual output; 6W; Vin 9V~36V; Vout ±5V; Iout ±600mA; isolation 3000V; RoHS; PFD6-18D05E2N3; AM5T-2405DZ; VRA2405ZP-6WR3; TP05DA24D05;

Parameters

Input voltage range:	9V ~ 36V
Output current 1:	600mA
Power:	6,0W
Output current 2:	600mA
Insulation breakdown voltage:	3000V
Secondary voltage 1:	5V
Secondary voltage 2:	-5V

All parameters

Manufacturer:: AIPULNION Manufacturer part number: PFD6-18D05E2N3 RoHS Case style: Rys.AM5TxxxxZ(dz,sz)

In stock:

10 pcs.

Quantity of pcs.	1+	3+	10+	30+	100+
Net price (EUR)	5,5630	5,1248	4,8558	4,7190	4,6355

Add to comparison tool Add inquiry (RFQ)

Packaging:
10 Quantity (multiple: 1)

- +

• Parameters

Input voltage range:	9V ~ 36V
Output current 1:	600mA
Power:	6,0W
Output current 2:	600mA
Insulation breakdown voltage:	3000V
Secondary voltage 1:	5V
Secondary voltage 2:	-5V
