High accuracy extra-safety multimeter with USB interface VA55 20000 counts

Micros part number: M VA55
Package: Rys.VA55
Voltage AC/DC, current AC/DC, resistance, capacitance, frequency
  Pozycja dostępna na zamówienie Ask about product
Detailed description

High accuracy multimeter with USB interface VA55

  • Made in conformity with IEC 61010-1: 2001, CAT III 1000V i CAT IV 600V
  • Max. display: 20000 counts
  • Double value display with analog bar
  • PC-LINK: USB
  • True RMS measurement
  • Relative measurement
  • MIN MAX value measurement
  • Auto power off
  • Data hold
  • Back light
  • Soundalarm for misplug
  • Auto / manual range
  • Low battery indication
  • DCV: 200mV/2V/20V/200V/1000V±(0.05%+10C)
  • ACV: 2V/20V/200V/1000V±0.5%+40C)
  • ACA: 200mA/10A±(1.0%+30C)
  • DCA: 200mA/10A±(0.2%+20C)
  • Resistance: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ±(0.5%+10C)
  • Capacitance: 20nF/200nF/2µF/20µF ±(1.5%+20C), 200µF/1000µF±(2.0%+20C)
  • Temperature: -200~-100°C±(1.0%+10C), -99~1300°C±(0.5%+10C)
  • Linear frequency: 10Hz~200kHz ±(0.05%+10C)
  • Logic frequency: 10Hz~2MHz ±(0.05%+10C)
  • Duty cycle: 10~90% ±(1%+30C)
  • Diode test
  • Continuity test
  • Power: 6F22 (9V)
  • Dimensions: 190 x 90 x 40 mm
  • Weight: 500g


V&A
