Brightek 1SC3528W61B0WEZ5

Symbol Micros: OLB.PLCC2.21000K

76678

OLB.PLCC2.21000K

Contractor Symbol:

Case : Rys.PLCC2

Datasheet

Technical drawing Add to favourites

3528 (PLCC2) LED; super cool white; 350 ~ 750mcd; 30mA; 120°; 2,8 ~ 3,8V; -40°C~80°C

Parameters

Manufacturer:	Brightek
Diode type:	LED
Mounting:	SMD
Case:	3528 (PLCC2)
LED colours:	Super cold white
Brightness:	350 ~ 750 mcd
Viewing angle:	120°

All parameters

Manufacturer:: BRIGHTEK Manufacturer part number: 1SC3528W61B0WEZ5 RoHS Case style: Rys.PLCC2 Datasheet

In stock:

683 pcs.

Quantity of pcs.	5+	20+	100+	500+	1943+
Net price (EUR)	0,2377	0,1308	0,0866	0,0720	0,0678

Add to comparison tool Add inquiry (RFQ)

Stock available
Until stock lasts Packaging:
1943 Quantity (multiple: 1)

- +

• Parameters

Manufacturer:	Brightek
Diode type:	LED
Mounting:	SMD
Case:	3528 (PLCC2)
LED colours:	Super cold white
Brightness:	350 ~ 750 mcd
Viewing angle:	120°
LED diode current:	30mA
Forvard volatge range:	2,8 ~ 3,8V
Colour temperature:	21000K
Operating temperature (range):	-40°C ~ 80°C
Chromatic coordinates:	x:0.15; y:0.19
