OS5RPMZ2C1P OPTOSUPPLY

Symbol Micros: OLCHP.7w4000a

298245

OLCHP.7w4000a

Contractor Symbol:

Case : Rys.OLBHP.5wk015

Datasheet

Technical drawing Add to favourites

LED; THT; SuperFlux; 5mm; red; 2000~4000mcd; 620~630nm; 70mA; 120°; 2.2~2.8V; -30~+80°C; 4 pins; waterclear

Parameters

Brightness:	2000~4000mcd
Colour:	Red
Diameter:	5mm
Forvard volatge range:	2,2~2,8V
Forward current:	70mA
Mounting:	THT
Operating temperature (range):	-30°C ~ 85°C

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Brightness:	2000~4000mcd
Colour:	Red
Diameter:	5mm
Forvard volatge range:	2,2~2,8V
Forward current:	70mA
Mounting:	THT
Operating temperature (range):	-30°C ~ 85°C
Viewing angle:	120°
Wavelength range:	620~630nm
