APF30224 Panasonic

Symbol Micros: P APF30224

121534

P APF30224

Contractor Symbol:

Case : APF Panasonic

Datasheet

Technical drawing Add to favourites

SPDT-NO; 24V DC; 6A; 170mW; 28 x 5 x 15mm PCB

Parameters

AC contact current:	6A
Coil power:	170mW
Coil voltage (V):	24V
Contacts configuration:	SPDT-NO
DC contact current:	6A
Dimensions:	28 x 5 x 15mm
Manufacturer:	PANASONIC

All parameters

Manufacturer:: Panasonic Manufacturer part number: APF30224 Case style: APF Panasonic

External warehouse:

1770 pcs.

Quantity of pcs.	10+ (Please wait for the order confirmation)
Net price (EUR)	3,2118

Add inquiry (RFQ)

Packaging:
10

Place an order

Delivery within 4-7 business days.
Minimum order amount
must exceed 40 Euro.

Manufacturer:: Panasonic Manufacturer part number: APF30224 Case style: APF Panasonic

External warehouse:

5581 pcs.

Quantity of pcs.	1000+ (Please wait for the order confirmation)
Net price (EUR)	1,5829

Add to comparison tool Add inquiry (RFQ)

Packaging:
1000

Place an order

Delivery within 4-7 business days.
Minimum order amount
must exceed 40 Euro.

• Parameters

AC contact current:	6A
Coil power:	170mW
Coil voltage (V):	24V
Contacts configuration:	SPDT-NO
DC contact current:	6A
Dimensions:	28 x 5 x 15mm
Manufacturer:	PANASONIC
Mounting:	PCB
