AZ943-1AH-05DE miniature power relay

Symbol Micros: P AZ943z005

95077

P AZ943z005

Contractor Symbol:

Case : Rys.AZ943z

Add to favourites

15A; 5V; SPST; coil power 203mW; 19 x 15,3 x 15,7mm SMT

Parameters

Type:	SPDT
Coil current type:	DC
Coil voltage (V):	5V
Contact current:	15A

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Type:	SPDT
Coil current type:	DC
Coil voltage (V):	5V
Contact current:	15A
