G6K-2F-Y-5DC miniature relay

Symbol Micros: P G6K2FY05

28720

P G6K2FY05

Contractor Symbol:

Case : Rys.G6K2FY

Datasheet

Add to favourites

5V; 1A; 100mW; DPDT; 10x6,5x5,2mm SMD

Parameters

Contacts configuration:	DPDT
Coil voltage type [AC, DC]:	DC
Coil voltage (V):	5V
AC contact current:	0,3A
DC contact current:	1A
Contact voltage:	max. 60V DC, max. 125V AC
Coil power:	100mW

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Contacts configuration:	DPDT
Coil voltage type [AC, DC]:	DC
Coil voltage (V):	5V
AC contact current:	0,3A
DC contact current:	1A
Contact voltage:	max. 60V DC, max. 125V AC
Coil power:	100mW
Mounting:	SMD
Manufacturer:	OMRON
Dimensions:	10x6,5x5,2mm
Operating temperature (range):	-40°C ~ 70°C
