HF115F/012-1ZS3AF (JQX-115F) power relay

Symbol Micros: P HF115f012-1zs3af
Contractor Symbol:
Case : Rys.JQX115F.3
Technical drawing Add to favourites
16A; 12V; SPDT; coil power 400mW; 29,0 x 16,0 x 13,0mm PCB; equivalent: RM85Z, RM83Z, AZ761, G2RL
Parameters
Type: SPDT
Coil current type: DC
Coil voltage (V): 12V
Contact current: 16A
Insulation breakdown voltage: 5000V
Manufacturer:: Hongfa Manufacturer part number: HF115F/012-1ZS3AF RoHS Case style: Rys.JQX115F.3 Datasheet
In stock:
500 pcs.
Quantity of pcs. 1+ 3+ 10+ 50+ 200+
Net price (EUR) 2,7149 2,2578 1,9877 1,8169 1,7522
Add to comparison tool
Packaging:
50/500
Type: SPDT
Coil current type: DC
Coil voltage (V): 12V
Contact current: 16A
Insulation breakdown voltage: 5000V
