NA-12W-K miniature relay

Symbol Micros: P NA12WK

111365

P NA12WK

Contractor Symbol:

Case : Rys.NA

Datasheet

Add to favourites

2A; 12V; DPDT; 14,9 x 7,4 x 9,7mm PCB

Parameters

Contacts configuration:	DPDT
Coil voltage (V):	12V
AC contact current:	2A
DC contact current:	2A
Contact voltage:	250VAC/220VDC
Coil power:	140mW
Mounting:	PCB

All parameters

Manufacturer:: Takamisawa Manufacturer part number: NA-12W-K RoHS Case style: Rys.NA

In stock:

15 pcs.

Quantity of pcs.	1+	5+	25+	50+	200+
Net price (EUR)	1,8740	1,3854	1,1919	1,1494	1,1022

Add to comparison tool Add inquiry (RFQ)

Packaging:
25/50 Quantity (multiple: 1)

- +

Manufacturer:: Takamisawa Manufacturer part number: NA-12W-K RoHS Case style: Rys.NA

In stock:

50 pcs.

Quantity of pcs.	1+	3+	10+	50+	200+
Net price (EUR)	2,0510	1,7206	1,5294	1,4114	1,3666

Add to comparison tool Add inquiry (RFQ)

Packaging:
50 Quantity (multiple: 1)

- +

• Parameters

Contacts configuration:	DPDT
Coil voltage (V):	12V
AC contact current:	2A
DC contact current:	2A
Contact voltage:	250VAC/220VDC
Coil power:	140mW
Mounting:	PCB
Manufacturer:	Fujitsu
Dimensions:	14,9x7,4x9,7mm
Operating temperature (range):	-40°C ~ 85°C
