P-3

Symbol Micros: P P03

331953

P P03

Contractor Symbol:

Case : RYS.P

Datasheet

Technical drawing Add to favourites

1A; 3V; DPDT; 140mW; 14,0 x 9,0 x 5,0mm; monostable; THT;

Parameters

AC contact current:	500mA
Coil power:	140mW
Coil voltage type [AC, DC]:	DC
Coil voltage (V):	3V
Contacts configuration:	DPDT
Contact voltage:	250VAC/220VDC
DC contact current:	2A

All parameters

Manufacturer:: Forward Relays Manufacturer part number: P-3 RoHS Case style: RYS.P Datasheet

In stock:

33 pcs.

Quantity of pcs.	1+	5+	25+	100+	400+
Net price (EUR)	1,4072	0,9855	0,8228	0,7655	0,7403

Add to comparison tool Add inquiry (RFQ)

Packaging:
25/100 Quantity (multiple: 1)

- +





Add inquiry (RFQ)

Item in delivery

Estimated date:
2027-01-30

Quantity of pcs.: 25

• Parameters

AC contact current:	500mA
Coil power:	140mW
Coil voltage type [AC, DC]:	DC
Coil voltage (V):	3V
Contacts configuration:	DPDT
Contact voltage:	250VAC/220VDC
DC contact current:	2A
Dimensions:	14,0 x 9,0 x 5,0mm
Manufacturer:	NFR
Mounting:	PCB
Operating temperature (range):	-40°C ~ 70°C
