BS12GB SAB Dip-switch

Symbol Micros: PRZ Dip12su

31249

PRZ Dip12su

Contractor Symbol:

Case : Rys.dwsDIP12s

Datasheet

Technical drawing Add to favourites

slide, 12 contacts; THT; blue color; gold plating 1u", height 5.20mm + knob 1.10mm; eqiv. DS-12, EDG12S; EDG112S

Parameters

Overall length:	31,48mm
Number of sections:	12
Manufacturer:	SAB
Mechanical durability:	5000 cycles
Colour:	Blue
Type of slider:	Raised
Mounting:	THT

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Overall length:	31,48mm
Number of sections:	12
Manufacturer:	SAB
Mechanical durability:	5000 cycles
Colour:	Blue
Type of slider:	Raised
Mounting:	THT
Terminal pitch:	2,54mm
