LM1086IS-3.3

Symbol Micros: ST1086is3.3

36923

ST1086is3.3

Contractor Symbol:

Case : TO263 (D2PAK)

Datasheet

Technical drawing Add to favourites

Positive Voltage Regulator, LDO, 3.3V, 1.5A, 1%, 1.3V dropout, -40÷125°C

Parameters

Output current [A]:	1,5A
Output voltage [V]:	3,3V
Tolerance [%]:	1%
Voltage drop:	1,3V
Working temperature range:	-40°C~125°C

All parameters

Manufacturer:: Texas Instruments Manufacturer part number: LM1086IS-3.3 RoHS Case style: TO263 (D2PAK)

In stock:

45 pcs.

Quantity of pcs.	1+	3+	10+	45+	135+
Net price (EUR)	2,3405	1,9101	1,6635	1,5146	1,4634

Add to comparison tool Add inquiry (RFQ)

Packaging:
45 Quantity (multiple: 1)

- +

Manufacturer:: Texas Instruments Manufacturer part number: LM1086ISX-3.3 RoHS Case style: TO263t/r (D2PAK)

In stock:

12 pcs.

Quantity of pcs.	1+	3+	10+	45+	135+
Net price (EUR)	2,3405	1,9101	1,6635	1,5146	1,4634

Add to comparison tool Add inquiry (RFQ)

Packaging:
50 Quantity (multiple: 1)

- +

• Parameters

Output current [A]:	1,5A
Output voltage [V]:	3,3V
Tolerance [%]:	1%
Voltage drop:	1,3V
Working temperature range:	-40°C~125°C
