TPS73601DCQ

Symbol Micros: ST73601dcq

139654

ST73601dcq

Contractor Symbol:

Case : SOT223-6

Datasheet

Technical drawing Add to favourites

Positive Voltage Regulator, ULDO, 1.2÷5.5V, 0.4A, 1%, 0.075V dropout, -40÷125°C TPS73601DCQG4, TPS73601DCQR, TPS73601DCQRG4

Parameters

Output voltage range [V]:	1.2V ~ 5.5V
Working temperature range:	-40 °C ~ 125 °C
Voltage drop:	0,075V
Output current [A]:	0,4A
Tolerance [%]:	1%
Input voltage range:	1,7V~5,5V

All parameters

Manufacturer:: Texas Instruments Manufacturer part number: TPS73601DCQ RoHS Case style: SOT223-6 Datasheet

In stock:

20 pcs.

Quantity of pcs.	1+	5+	20+	100+	300+
Net price (EUR)	2,5366	2,0142	1,8194	1,7232	1,6911

Add to comparison tool Add inquiry (RFQ)

Packaging:
20 Quantity (multiple: 1)

- +

• Parameters

Output voltage range [V]:	1.2V ~ 5.5V
Working temperature range:	-40 °C ~ 125 °C
Voltage drop:	0,075V
Output current [A]:	0,4A
Tolerance [%]:	1%
Input voltage range:	1,7V~5,5V
