2SC2078 SLKOR

Symbol Micros: T2SC2078 SLK

349390

T2SC2078 SLK

Contractor Symbol:

Case : TO220

Datasheet

Technical drawing Add to favourites

NPN Transistor; 200; 12W; 35V; 5A; 200MHz; -65°C ~ 175°C;

Parameters

Power dissipation:	12W
Manufacturer:	SLKOR
Current gain factor:	200
Case:	TO220
Cutoff frequency:	200MHz
Max. collector current:	5A
Max collector-emmiter voltage:	35V

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Power dissipation:	12W
Manufacturer:	SLKOR
Current gain factor:	200
Case:	TO220
Cutoff frequency:	200MHz
Max. collector current:	5A
Max collector-emmiter voltage:	35V
Operating temperature (range):	-65°C ~ 175°C
Transistor type:	NPN
