BU2520DF SOT199

Symbol Micros: TBU2520df

11179

TBU2520df

Contractor Symbol:

Case : TO 3Piso (SOT199)

Datasheet

Technical drawing Add to favourites

NPN 10A 800V 45W Replacement: BU2520DX

Parameters

Power dissipation:	45W
Current gain factor:	13
Case:	TO 3Piso (SOT199)
Max. collector current:	10A
Max collector-emmiter voltage:	800V
Operating temperature (range):	-65°C ~ 150°C
Transistor type:	NPN

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Power dissipation:	45W
Current gain factor:	13
Case:	TO 3Piso (SOT199)
Max. collector current:	10A
Max collector-emmiter voltage:	800V
Operating temperature (range):	-65°C ~ 150°C
Transistor type:	NPN
