PTCCL13H281HBE Vishay Thermistor

Symbol Micros: TE PTCCL13H281HBE

410590

TE PTCCL13H281HBE

Contractor Symbol:

Case : Rys.PTCCL13HxxxHBE

Datasheet

Technical drawing Add to favourites

Thermistor PTC; 265V; 280mA; 11R; dimensions: 12,5x5,5mm; r=5mm; operating temperature: 0°C~70°C

Parameters

Resistance:	11 Ohm
Current:	0,28A
Diameter:	12,5mm
Operating voltage:	265V
Thickness [m]:	5,5mm
Manufacturer:	VISHAY
Terminal pitch:	5mm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Resistance:	11 Ohm
Current:	0,28A
Diameter:	12,5mm
Operating voltage:	265V
Thickness [m]:	5,5mm
Manufacturer:	VISHAY
Terminal pitch:	5mm
Operating temperature (range):	0°C ~ 70°C
