IT233 Schaffner Impulse transformer

Symbol Micros: TR IT233

535068

TR IT233

Contractor Symbol:

Case : Rys.IT233

Datasheet

Add to favourites

3mH; 0.25A; 1:1:1; 500V; PCB; 800mR; 27x22,5x13,7mm

Parameters

Lenght:	27mm
Width [mm]:	22,5mm
Inductance:	3mH
Height [mm]:	13,7mm
Manufacturer:	Schaffner
Mounting:	PCB
Transformator type:	Impulsowy

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Lenght:	27mm
Width [mm]:	22,5mm
Inductance:	3mH
Height [mm]:	13,7mm
Manufacturer:	Schaffner
Mounting:	PCB
Transformator type:	Impulsowy
