AX1000 Talema Current transformer

Symbol Micros: TR P AX1000

268471

TR P AX1000

Contractor Symbol:

Case : Rys.AX

Datasheet

Technical drawing Add to favourites

Turns ratio: 1000:1; winding resistance: 100R; I:10A; DCR: 93R; pins; dimensions: 17.20x9.53x20,4mm





Add inquiry (RFQ)

Item available on request
