VN20.10/09477 MARSCHNER Encapsulated transformer

Symbol Micros: TR Z00.50/09b MAR
Contractor Symbol:
Case : Rys.VN20.10
Technical drawing Add to favourites
Encapsulated transformer; 0.5VA; 230V/9V; 55mA; Ta=70°C; H=19mm; equivalent: TEZ0.5/D230/9V; BV 202 0157; TR Z00.50/09b II
Parameters
VA power: 0,5VA
Input voltage: 230V
Secondary voltage 1: 9V
Thermal class: 70°C
Mounting: PCB
Transformator type: Encapsulated transformer
Manufacturer: MARSCHNER


Item available on request
VA power: 0,5VA
Input voltage: 230V
Secondary voltage 1: 9V
Thermal class: 70°C
Mounting: PCB
Transformator type: Encapsulated transformer
Manufacturer: MARSCHNER
Secondary winding current 1: 55mA
