BV EI 301 3588 Hahn  Encapsulated transformer

Symbol Micros: TR Z00.70/12b Hahn

404600

TR Z00.70/12b Hahn

Contractor Symbol:

Case : Rys.BV EI 301

Datasheet

Technical drawing Add to favourites

Encapsulated transformer; 0.7VA; 230V/12V; 58mA; Ta=70°C; H=15,2mm;

Parameters

VA power:	0,7VA
Input voltage:	230V
Secondary voltage 1:	12V
Thermal class:	70°C
Mounting:	PCB
Transformator type:	Encapsulated transformer
Manufacturer:	Hahn

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

VA power:	0,7VA
Input voltage:	230V
Secondary voltage 1:	12V
Thermal class:	70°C
Mounting:	PCB
Transformator type:	Encapsulated transformer
Manufacturer:	Hahn
Secondary winding current 1:	58mA
