BV EI 306 3365 Hahn Encapsulated transformer

Symbol Micros: TR Z03.00/06b IIHahn

271069

TR Z03.00/06b IIHahn

Contractor Symbol:

Case : Rys.TRZ15

Datasheet

Technical drawing Add to favourites

Encapsulated transformer; 3.0VA; 230V/6V; 250mA; Ta=70°C

Parameters

VA power:	3VA
Input voltage:	230V
Secondary voltage 1:	6V
Thermal class:	70°C
Mounting:	PCB
Transformator type:	Encapsulated transformer
Manufacturer:	Hahn

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

VA power:	3VA
Input voltage:	230V
Secondary voltage 1:	6V
Thermal class:	70°C
Mounting:	PCB
Transformator type:	Encapsulated transformer
Manufacturer:	Hahn
Secondary winding current 1:	250mA
