LGE3415ES

Symbol Micros: TSI3415B-TP LGE

407739

TSI3415B-TP LGE

Contractor Symbol:

Case : SOT23

Datasheet

Technical drawing Add to favourites

P-CHANNEL MOSFET, SOT-23 Substitute: SI3415B-TP;

Parameters

Open channel resistance:	50mOhm
Max. drain current:	-4A
Max. power loss:	1,4W
Case:	SOT23
Manufacturer:	LGE
Max. drain-source voltage:	-20V
Transistor type:	P-MOSFET

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Open channel resistance:	50mOhm
Max. drain current:	-4A
Max. power loss:	1,4W
Case:	SOT23
Manufacturer:	LGE
Max. drain-source voltage:	-20V
Transistor type:	P-MOSFET
Max. gate-source Voltage:	10V
Operating temperature (range):	-55°C ~ 150°C
Mounting:	SMD
