SUD40N10-25-E3

Symbol Micros: TSUD40N10-25

106946

TSUD40N10-25

Contractor Symbol:

Case : TO252 (DPACK)

Datasheet

Technical drawing Add to favourites

Trans MOSFET N-CH 100V 40A 3-Pin(2+Tab) DPAK

Parameters

Open channel resistance:	63mOhm
Max. drain current:	40A
Max. power loss:	136W
Case:	TO252 (DPACK)
Manufacturer:	VISHAY
Max. drain-source voltage:	100V
Transistor type:	N-MOSFET

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Open channel resistance:	63mOhm
Max. drain current:	40A
Max. power loss:	136W
Case:	TO252 (DPACK)
Manufacturer:	VISHAY
Max. drain-source voltage:	100V
Transistor type:	N-MOSFET
Max. gate-source Voltage:	20V
Operating temperature (range):	-55°C ~ 175°C
Mounting:	SMT
