SUD50P04-09L-E3

Symbol Micros: TSUD50P04-09L-E3 VBS

367636

TSUD50P04-09L-E3 VBS

Contractor Symbol:

Case : TO252

Datasheet

Technical drawing Add to favourites

Transistor P-Channel MOSFET; -40V; +/-20V; 59mOhm; -50A; 136W; -55°C~175°C;

Parameters

Open channel resistance:	20mOhm
Max. drain current:	-50A
Max. power loss:	136W
Case:	TO252
Manufacturer:	VBsemi
Max. drain-source voltage:	-40V
Max. gate-source Voltage:	20V

All parameters

Manufacturer:: VBsemi Manufacturer part number: SUD50P04-09L-E3-VB RoHS Case style: TO252t/r Datasheet

In stock:

60 pcs.

Quantity of pcs.	1+	5+	20+	100+	400+
Net price (EUR)	1,1383	0,7968	0,6762	0,6192	0,5987

Add to comparison tool Add inquiry (RFQ)

Packaging:
100 Quantity (multiple: 1)

- +

• Parameters

Open channel resistance:	20mOhm
Max. drain current:	-50A
Max. power loss:	136W
Case:	TO252
Manufacturer:	VBsemi
Max. drain-source voltage:	-40V
Max. gate-source Voltage:	20V
Transistor type:	P-MOSFET
Operating temperature (range):	-55°C ~ 175°C
Mounting:	SMD
