DSM1-2411

Symbol Micros: UIAM1L2405snz c

103432

UIAM1L2405snz c

Contractor Symbol:

Case : Rys.AM1L-xxxxS

Datasheet

Technical drawing Add to favourites

DC-DC Converter; Isolated; Single Output; 1W; 200mA; 5V; 1,5kV; 21,6V~26,4V; -40°C~85°C; EFF 68%; Substitute: AM1L-2405S-NZ;

Parameters

Input voltage range:	21,6V ~ 26,4V
Output current:	0,2A
Output voltage range [V]:	5V
Efficiency:	68%
Power:	1W
Input voltage:	24V
Output current 1:	200mA

All parameters

Manufacturer:: PAIRUI Manufacturer part number: DSM1-2411 RoHS Case style: Rys.AM1L-xxxxS Datasheet

In stock:

5 pcs.

Quantity of pcs.	1+	5+	20+	50+	200+
Net price (EUR)	2,7908	2,2974	2,1108	2,0471	1,9928

Add to comparison tool Add inquiry (RFQ)

Packaging:
5 Quantity (multiple: 1)

- +

• Parameters

Input voltage range:	21,6V ~ 26,4V
Output current:	0,2A
Output voltage range [V]:	5V
Efficiency:	68%
Power:	1W
Input voltage:	24V
Output current 1:	200mA
Output voltage:	5V
Insulation breakdown voltage:	1500V
Secondary voltage 1:	5V
