DAE1-1211

Symbol Micros: UIDAE11211

113660

UIDAE11211

Contractor Symbol:

Case : SIP 7

Datasheet

Technical drawing Add to favourites

1W DC-DC Conv; Unregulated, 1KVDC; Vin 12V; Vout 5V; Single; 40°C~85°C; Substitute: AM1D-1205SZ;

Parameters

Output current [A]:	0,2A
Input voltage range:	10,8V~13,2V
Input voltage:	12V
Output voltage range [V]:	12V
Efficiency:	71%
Power:	1W
Output voltage [V]:	12V

All parameters

Manufacturer:: PAIRUI Manufacturer part number: DAE1-1211 RoHS Case style: SIP 7 Datasheet

In stock:

10 pcs.

Quantity of pcs.	1+	3+	10+	30+	100+
Net price (EUR)	2,8777	2,4754	2,2377	2,1234	2,0549

Add to comparison tool Add inquiry (RFQ)

Packaging:
10 Quantity (multiple: 1)

- +

• Parameters

Output current [A]:	0,2A
Input voltage range:	10,8V~13,2V
Input voltage:	12V
Output voltage range [V]:	12V
Efficiency:	71%
Power:	1W
Output voltage [V]:	12V
Secondary voltage 1:	12V
Insulation breakdown voltage:	1000V
