RT8075ZQW

Symbol Micros: UIRT8075zqw

299942

UIRT8075zqw

Contractor Symbol:

Case : WDFN10(3x3)

Datasheet

Technical drawing Add to favourites

2-Ch Step-Down Switching Regulator, 1A, Vin 2.5÷5.5V, Vout 0.6÷5.5V, 1.25MHz

Parameters

Manufacturer:	RICHTEK
Integrated circuit type:	Switching regulator
Input voltage range:	2.5V ~ 5.5V
Mounting:	SMD
Case:	WDFN10(3x3)
Dimensions:	3.0x3.0x0.8mm
Operating temperature (range):	-40°C ~ 85°C

All parameters

Manufacturer:: RICHTEK Manufacturer part number: RT8075ZQW RoHS Case style: WDFN10(3x3) Datasheet

In stock:

50 pcs.

Quantity of pcs.	2+	10+	50+	200+	1000+
Net price (EUR)	0,8310	0,5259	0,4155	0,3780	0,3615

Add to comparison tool Add inquiry (RFQ)

Packaging:
50 Quantity (multiple: 1)

- +

• Parameters

Manufacturer:	RICHTEK
Integrated circuit type:	Switching regulator
Input voltage range:	2.5V ~ 5.5V
Mounting:	SMD
Case:	WDFN10(3x3)
Dimensions:	3.0x3.0x0.8mm
Operating temperature (range):	-40°C ~ 85°C
