09 15 200 0403 HARTING

Symbol Micros: Z 09152000403

56624

Z 09152000403

Contractor Symbol:

Case : Rys.09152000403

Technical drawing Add to favourites

Han R23 Hood Top Entry PG 11 straight, for calbe

Product description





Add inquiry (RFQ)

Item available on request

• Description

Detailed description

Micros Part Number	Z 09152000403
Manufacturer Part Number	09 15 200 0403
Locking type	screw locking
Type of hood/housing	Hoods
Series	R 23
Limiting temperature, min.	-40 °C
Limiting temperature, max.	115 °C
