DG238-10.0-03P-19-01A DEGSON Terminal block

Symbol Micros: Z DG238-10.0/3

35804

Z DG238-10.0/3

Contractor Symbol:

Case : Rys.DG238-10.0/3

Datasheet

Technical drawing Add to favourites

3 poles, pitch 10mm, heigth 11.6mm, white colour, w/o ground pin, 450V, 24A (VDE), 0.75-2.5mm2, PA66 material

Parameters

Height [mm]:	11,6mm
Terminal pitch [mm]:	10,0mm
Number of pins:	3
Colour:	White
Manufacturer:	DEGSON

All parameters

Manufacturer:: DEGSON Manufacturer part number: DG238-10.0-03P-19-01Z(H) RoHS Case style: Rys.DG238-10.0/3 Datasheet

In stock:

2195 pcs.

Quantity of pcs.	1+	3+	10+	50+	200+
Net price (EUR)	0,8510	0,6246	0,5002	0,4300	0,4051

Add to comparison tool Add inquiry (RFQ)

Packaging:
50/200 Quantity (multiple: 1)

- +

• Parameters

Height [mm]:	11,6mm
Terminal pitch [mm]:	10,0mm
Number of pins:	3
Colour:	White
Manufacturer:	DEGSON
