CH-254-PH-1-40-25-RD-138-GO-A CONNECTAR Pin header

Symbol Micros: Z L1x40RN

15996

Z L1x40RN

Contractor Symbol:

Case : Rys.L1x40RN

Datasheet

Technical drawing Add to favourites

male; single row; 1x40pin, angled (low profile), p.2,54mm, PCB, gold contact; eqiv. PLS-40RD, ZL211-40KG

Parameters

Type of pin configuration:	1x40
Number of pins:	40
Type of connector:	Plug
Connector:	Pin strip
Mounting:	THT
Spatial orientation:	Angled
Terminal pitch [mm]:	2,54mm

All parameters

Manufacturer:: CONNECTAR Manufacturer part number: CH-254-PH-1-40-25-RD-138-GO-A RoHS Case style: Rys.L1x40RN Datasheet

In stock:

0 pcs.

Quantity of pcs.	3+	10+	20+	50+	116+
Net price (EUR)	0,2701	0,1725	0,1435	0,1210	0,1096

Add to comparison tool Add inquiry (RFQ)

Packaging:
116 Quantity (multiple: 1)

- +

Manufacturer:: CONNECTAR Manufacturer part number: CH-254-PH-1-40-25-RD-138-GO-A RoHS Case style: Rys.L1x40RN Datasheet

In stock:

36543 pcs.

Quantity of pcs.	3+	10+	50+	200+	1000+
Net price (EUR)	0,2701	0,1725	0,1210	0,1051	0,0983

Add to comparison tool Add inquiry (RFQ)

Packaging:
200/4800/9600 Quantity (multiple: 1)

- +





Add inquiry (RFQ)

Item in delivery

Estimated date:
2026-12-10

Quantity of pcs.: 38400

• Parameters

Type of pin configuration:	1x40
Number of pins:	40
Type of connector:	Plug
Connector:	Pin strip
Mounting:	THT
Spatial orientation:	Angled
Terminal pitch [mm]:	2,54mm
