CH-254-PH-2-05-254-M-G0-A W7.4PA6.0 CONNECTAR Pin header

Symbol Micros: Z L2x05 SMD

121350

Z L2x05 SMD

Contractor Symbol:

Case : Rys.L2x05SMD

Datasheet

Add to favourites

pin header dual row 2x05pin, straight, p.2,54mm, SMD, gold contact; with pick&place; eqiv. PLTD10S-JL-TR

Parameters

Type of pin configuration:	2x05
Number of pins:	10
Type of connector:	Plug
Connector:	Pin strip
Mounting:	SMD
Spatial orientation:	Straight
Terminal pitch [m]:	2,54mm

All parameters

Manufacturer:: CONNECTAR Manufacturer part number: CH-254-PH-2-05-254-M-G0-A W7.4PA6.0 RoHS Case style: Rys.L2x05SMD Datasheet

In stock:

4706 pcs.

Quantity of pcs.	3+	20+	100+	300+	1000+
Net price (EUR)	0,4316	0,2382	0,1866	0,1726	0,1656

Add to comparison tool Add inquiry (RFQ)

Packaging:
1000 Quantity (multiple: 1)

- +

• Parameters

Type of pin configuration:	2x05
Number of pins:	10
Type of connector:	Plug
Connector:	Pin strip
Mounting:	SMD
Spatial orientation:	Straight
Terminal pitch [m]:	2,54mm
