CH-254-PH-1-20-S-30/104/60-GO-A CONNECTAR Double deck pin header

Symbol Micros: Z LDS1x40-19.4

45420

Z LDS1x40-19.4

Contractor Symbol:

Case : Rys.LDS1x40-19.4

Datasheet

Add to favourites

male; straight; 1x40pin; pitch 2,54mm; overall length: 19,4mm (10,4mm)

Parameters

Overall length:	19,4mm
Number of pins:	1x40
Manufacturer:	CONNECTAR
Mounting:	THT
Terminal pitch [m]:	2,54mm

All parameters

Manufacturer:: CONNECTAR Manufacturer part number:   Case style: Rys.LDS1x40-19.4 Datasheet

In stock:

1535 pcs.

Quantity of pcs.	3+	20+	100+	500+	2000+
Net price (EUR)	0,4380	0,2436	0,1923	0,1745	0,1689

Add to comparison tool Add inquiry (RFQ)

Packaging:
100/2000/4000 Quantity (multiple: 1)

- +





Add inquiry (RFQ)

Item in delivery

Estimated date:
2026-08-01

Quantity of pcs.: 6000

• Parameters

Overall length:	19,4mm
Number of pins:	1x40
Manufacturer:	CONNECTAR
Mounting:	THT
Terminal pitch [m]:	2,54mm
