Z LG1x03S5

Symbol Micros: Z LG1x05S5

534186

Z LG1x05S5

Contractor Symbol:

Case : Rys.LG1x05S5

Technical drawing Add to favourites

female; single row 1x5pin, staright, p.2.54mm, PCB, gold contact; h= 5mm

Parameters

Type of pin configuration:	1x05
Number of pins:	5
Type of connector:	Socket
Connector:	Socket pin strips
Mounting:	THT
Spatial orientation:	Straight
Terminal pitch [m]:	2,54mm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Type of pin configuration:	1x05
Number of pins:	5
Type of connector:	Socket
Connector:	Socket pin strips
Mounting:	THT
Spatial orientation:	Straight
Terminal pitch [m]:	2,54mm
