H4030-14PDB000R HSM Cable connector

Symbol Micros: Z MFZ14

27515

Z MFZ14

Contractor Symbol:

Case : Rys.MFZ14

Datasheet

Technical drawing Add to favourites

plug; male; MICRO-FIT 14pin; type of pin configuration: 2x7; pitch: 3.0mm mate with MFM, eqiv.MOLEX MX-43020-1400

Parameters

Number of pins:	14
Type of pin configuration:	2x7
Manufacturer:	HSM
Mounting:	Cables
Connector:	Plug
Type of connector:	Male

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Number of pins:	14
Type of pin configuration:	2x7
Manufacturer:	HSM
Mounting:	Cables
Connector:	Plug
Type of connector:	Male
