XY2500R-G(3.5)-04P (black) XINYA Terminal block

Symbol Micros: Z TLPHC001r-04p-bk

497830

Z TLPHC001r-04p-bk

Contractor Symbol:

Case : Rys.TLPHC001r-04p

Datasheet

Technical drawing Add to favourites

4 poles; pitch: 3.5mm; height: 7.0mm; black color, 300V; 8A, angled, mates with TLPS001 / TLPSZ001 3.5mm solder pin: brass, tin plated; eqiv. MC 1,5/ 4-G-3,5; 1844236; 15EDGRC-3.5-04P

Parameters

Height:	7,0mm
Number of pins:	4
Terminal pitch:	3,5mm
Colour:	Black
Manufacturer:	XINYA

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Height:	7,0mm
Number of pins:	4
Terminal pitch:	3,5mm
Colour:	Black
Manufacturer:	XINYA
