XY2500V-F(3.5)-05P (black) XINYA Terminal block

Symbol Micros: Z TLPHC001v-05p-bk

497828

Z TLPHC001v-05p-bk

Contractor Symbol:

Case : Rys.TLPHC001v-05p

Datasheet

Technical drawing Add to favourites

5 poles; pitch: 3.5mm; height: 9.1mm; black color, 300V; 8A, straight, mates with TLPS001 / TLPSZ001 3.5mm solder pin: brass, tin plated; eqiv. MCV 1,5/ 5-G-3,5; 1843635; 15EDGVC-3.5-05P

Parameters

Height:	9,1mm
Number of pins:	5
Terminal pitch:	3,5mm
Colour:	Black
Manufacturer:	XINYA

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Height:	9,1mm
Number of pins:	5
Terminal pitch:	3,5mm
Colour:	Black
Manufacturer:	XINYA
