XY2500R-B(5.0)-23P XINYA Terminal block

Symbol Micros: Z TLPHC200r-23p

57025

Z TLPHC200r-23p

Contractor Symbol:

Case : Rys.TLPHC200r-23p

Datasheet

Technical drawing Technical drawing Add to favourites

23 poles; pitch: 5,00mm; height 8.4mm; green colour; close, 300V; 15A; angled, mates with TLPS 5,00mm solder pin: brass; tin plated; equivalent: MSTBA 2,5/23-G; 1757679; 2EDGRC-5.0-23P

Parameters

Height:	12,0mm
Number of pins:	23
Colour:	Green
Manufacturer:	XINYA
Terminal pitch:	5,0mm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Height:	12,0mm
Number of pins:	23
Colour:	Green
Manufacturer:	XINYA
Terminal pitch:	5,0mm
