XY2500F-C(3.81)-16P XINYA

Symbol Micros: Z TLPS100v-16p

52611

Z TLPS100v-16p

Contractor Symbol:

Case : Rys.TLPS100v-16p

Datasheet

Technical drawing Add to favourites

16 poles,pitch 3.81mm,height 15.4mm,green color,clamp:phosphor bronze,tin plated, 300V, 8A, 28-16AWG, mates with TLPHC100 3.81mm wire cage: brass,nickel plated, screw: steel, zinc plated

Parameters

Height:	15,4mm
Number of pins:	16
Terminal pitch:	3,81mm
Colour:	Green
Manufacturer:	XINYA

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Height:	15,4mm
Number of pins:	16
Terminal pitch:	3,81mm
Colour:	Green
Manufacturer:	XINYA
