2EDGKQ-5.0-03P-13-00AH DEGSON Terminal block

Symbol Micros: Z2EDGKQ-5.0/03

102917

Z2EDGKQ-5.0/03

Contractor Symbol:

Case : Rys.2EDGKQ-5.0/03

Datasheet

Technical drawing Add to favourites

3 poles; pitch: 5.0mm; height 10.5mm; green color 300V (UL), 20A, 0.2-2.5mm / 28-14AWG

Parameters

Height:	10,5mm
Number of pins:	3
Colour:	Black
Manufacturer:	DEGSON
Terminal pitch:	5,0mm

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Height:	10,5mm
Number of pins:	3
Colour:	Black
Manufacturer:	DEGSON
Terminal pitch:	5,0mm
