8EDGK-3.5-12P-11-01ZH DEGSON Termianl block

Symbol Micros: Z8EDGK-3.5/12

63431

Z8EDGK-3.5/12

Contractor Symbol:

Case : Rys.8EDGK-3.5/12

Datasheet

Technical drawing Add to favourites

12 poles; pitch: 3.5mm; height: 18.6mm; grey color,

Parameters

Height:	18,6mm
Number of pins:	12
Terminal pitch:	3,5mm
Colour:	Grey
Manufacturer:	DEGSON

All parameters





Add inquiry (RFQ)

Item available on request

• Parameters

Height:	18,6mm
Number of pins:	12
Terminal pitch:	3,5mm
Colour:	Grey
Manufacturer:	DEGSON
